PANOR α
PANOR α
Product Features
-180 degree panoramic window
-Viewing area：115X85MM
-Side window can be automatically dimmed
-High quality lens
-HD filter
-Sensors：4
-Optical rating：1/1/1/1
-Grinding function：DIN3
-Viewing area：115X85MM
-Side window can be automatically dimmed
-High quality lens
-HD filter
-Sensors：4
-Optical rating：1/1/1/1
-Grinding function：DIN3
Product Description
TECHNICAL DESCRIPTION
| filter model： | PANORα |
| Optical rating： | 1/1/1/1 |
| Viewing area： | 115x85 mm main window35/80x68 mm side windows |
| Lens Shade (DIN)： | 4-8/8-12 main window10 side windows |
| Sensors： | 4 |
| Light State (DlN)main window/side windows： | 3 |
| UV/lR Protection： | Up to DIN 16 |
| On / off： | Automatic |
| Switch time (light to dark)： | 0.04ms |
| Shade control： | Outside & Stepless |
| Light Sensitivity Control： | Outside, Low-High; adjust by infinitely dial knob |
| Delay control/Delay time (dark to light)： | Outside, 0.15-0.80s by infinitely dial knob |
| TlG amps rated： | ≥2 amps |
| Grind mode： | Yes, outside |
| Weight： | 610 gr |
| Operation temperature： | ~-5℃ (23°F)- +55℃ (131°F) |
| Storing TemperaturePower Supply： | ~ -20℃ (-4°F)- +70℃ (158°F) |
| Solar power & replaceable battery： | 2xCR245O Lithium battery |
