WH1501
WH1501
Product Features
-Viewing area：92X42MM
-Optical class：1/1/1/2
-Available Shade：DIN9-13
-sensitivity &delay time：Inside& Switch
-Sensors：2 -TIG capability：＞5A
-Optical class：1/1/1/2
-Available Shade：DIN9-13
-sensitivity &delay time：Inside& Switch
-Sensors：2 -TIG capability：＞5A
Product Description
TECHNICAL DESCRIPTION
| Filter model： | WH501 |
| Light state： | DIN4 |
| Dark state： | DIN9-13 |
| Switching time： | <0.04ms |
| Optical class： | 1/1/1/2 |
| Cartridge Size： | 110x 90 x 8mm (5.25x4.5 x0.35" ) |
| Viewing area： |
92 x 42 mm (3.94x2.64" ) |
| Sensitivity： | Inside& Switch(Low/High) |
| Delay time： | Inside&Switch(Fast/Slow 0.20S ~0.60S) |
| Shade Adjustment： | Outside &Stepless |
| Sensors： | 2 |
| TIG Capability： | > 5A |
| Grinding： | Inside |
| Power Supply： | Li-Mn & Solar Combination |
| UV & IR protection： | Up to shade 16 |
| Weight： | 390G (0.86 Pound) |
| Material of helmet： | PP EN175 |
| Warranty (years)： | 2 |
| Available color： | blue/black/silver/red/other pattern |
| Certification： | CE, ANSI |
