产品名称
WH8512
-Optical class:1/1/1/2
-Available Shade:DIN9-13
-sensitivity &delay time:Stepless
-Sensors:2
-TIG capability:>5A
PRODUCT DESCRIPTION
TECHNICAL DESCRIPTION
Filter model: | WH512 |
Light state: | DIN4 |
Dark state: | DIN9-13 |
Switching time: | <0.04mS |
Optical class: | 1/1/1/2 |
Cartridge Size: | 110 x 90 x 8 mm |
Viewing area: |
92 x 42mm |
Shade Adjustment: | Outside & Stepless |
Delay time: | Stepless Adjustment 0.15S ~0.80S |
Sensors: | 2 |
TIG Capability: | > 5A |
Power Supply: | Replaceable Li-Mn & Solar Combination |
UV & IR protection: | Up to shade 16 |
Weight: | 490G |
Material of helmet: | NYLON EN175B |
Operation temperature: | -5℃( 23 °F)-+55℃( 131° F) |
Warranty (years): | 2 |
Available color: | blue/black/silver/red/other pattern |
Certification: | CE, ANSI |
